The PanL35L Display provides users an intuitive interface option to monitor and trigger control events. It is based on a 3.5 inch 320 x 240 pixel TFT LCD panel powered by Bridgetek’s very own Embedded Video Engine (EVE) Graphic Controller chip that enables rich and intuitive GUI`s displays. It also comes with built in buzzer and Wi-Fi module for wireless connectivity. The display is also furnished with a RGB LED strip light indicator where different color codes can be programmed to represent a certain application event. The display can be placed on any flat surface area. The PanL35L is powered by the included 5V Micro-USB adaptor and cable.
- Dual-Core 32-bit LX6 microcontroller (MCU)
- Built-in advanced FT813Q graphics controller with display and audio functionality
- 3.5″ high brightness TFT LCD (320*240 pixels)
- Supports Wi-Fi 802.11b/g/n (2.4GHz), up to 150Mbps
- Built In Buzzer
- RGB LED Strip Indicator
- Micro USB Type B Port
- DC Power: 5V / 1A
- Operating temperature range : 0oC to +55oC
Your hot desking solution for better management of co-sharing spaces:
Eliminate manual booking and release of desks. Maximizing user to desk ratio.
Make on-spot desk reservations right from the desk panl (QR Code) or advance booking through Outlook or mobile app.
Quickly spot desk
Clear LED indicators to distinguish between vacant and occupied desks.
Upload floor maps and assign desk location for intuitive booking experience.
Office365 & Outlook Exchange
Integrate and synchronize with existing Microsoft Outlook calendar seamlessly
Re-conditioning of shared workspace using statistical data for cost and space savings.
Quick scale and deploy
Easily scale up number of desks with wireless enabled displays powered by micro-USB.
Centralized console to manage configuration, booking resources and policies.
